Home > Á¦Á¶±â¼ú&¿¬±¸°³¹ß > Á¦Á¶±â¼ú |
|
|
|
|
![](/images/page/tech01_0501.gif) |
|
![](/images/page/tech01_0502.gif) |
|
Item |
Description |
Remark |
PCB Size |
750 x 560 |
Max. |
PCB Layer |
50L |
|
PCB Thickness |
4.8T |
Max. : 6.3T |
Drill Size |
0.15mm / 0.2mm |
Min. |
Impedance Control |
50§Ù +/- 10% |
Special +/- 7.5% |
Pin Pitch |
0.4mm |
|
PCB Material |
FR-4 / High TG / PPE |
|
|
|
|
|
